? Message us on Cisco GLC-T module, which is used to create fiber optic port and is designed for Cisco switches, and this module is of SFP type. In this topic, we would like to review, price and buy fiber optic module GLC-T of Cisco brand. Stay with us.
What is a Transceiver Module
A transceiver module, or transceiver, is a networking device that transmits and receives data via a communication channel. It integrates the transmitter and receiver functions into a single module, enabling bidirectional communication between network devices. Transceiver modules are widely used in networking equipment such as switches, routers, and network interface cards (NICs) to enable data transmission via a variety of media, including copper cables, fiber optic cables, and wireless connections.
These modules are available in a variety of form factors, including Small Form Factor Pluggable (SFP), Gigabit Interface Converter (GBIC), and Quad Small Form Factor Pluggable (QSFP), among others. They support a variety of data rates, wavelengths, and transmission distances based on the network’s specific requirements. Overall, transceiver modules play an important role in modern networking by allowing network devices to communicate reliably and efficiently across many media.
Cisco GLC-T SFP Transceiver Module
The Cisco GLC-T SFP Transceiver Module is a high-performance, hot-swappable transceiver intended for Gigabit Ethernet applications using copper cabling. It offers data rates of up to 1 Gbps and works with Category 5e or higher unshielded twisted-pair (UTP) cables, enabling for flexible and cost-effective network expansions. With an RJ-45 connector, this module has a maximum distance of 100 meters, making it suitable for connecting switches, routers, and other network equipment inside a local area network (LAN).
The GLC-T transceiver complies fully with IEEE 802.3 standards, ensuring simple integration with existing network infrastructure. Its hot-swappable design enables simple installation and replacement without affecting network operations. Designed for robust and reliable performance, the Cisco GLC-T is a versatile solution for enhancing network connectivity and scalability in both enterprise and data center environments.
Cisco GLC-T Module Key Features
- Gigabit Ethernet: Supports data speeds of up to 1 Gbps for high-speed network connectivity.
- Copper cable: Use Category 5e or higher unshielded twisted-pair (UTP) copper cable.
- RJ-45 Connector: Includes an RJ-45 connector for quick and dependable connections.
- Maximum Distance: Data can be transmitted over distances of up to 100 meters.
- Hot-swappable: Enables installation and replacement without the need to power down network equipment, resulting in little disturbance.
- IEEE 802.3 Compliance: Completely compliant with IEEE 802.3 standards, ensuring interoperability with a wide range of network devices.
- Energy-Efficient: Designed to use minimal power, making it ideal for energy-conscious environments.
- Durable Design: Designed to provide strong and consistent performance under a variety of network situations.
- Wide Compatibility: Works with a wide range of Cisco switches, routers, and other networking devices.
- Easy Deployment: The plug-and-play feature simplifies network expansions and upgrades.
GLC-T VS FET-10G
| Feature | Cisco GLC-T | Cisco FET-10G |
|---|---|---|
| Data Rate | 1 Gbps (Gigabit Ethernet) | 10 Gbps (10 Gigabit Ethernet) |
| Wavelength | N/A | 850 nm (Multimode Fiber), 1310 nm (Single Mode) |
| Fiber Type | Category 5e or higher unshielded twisted-pair (UTP) | Multimode Fiber (MMF), Single Mode Fiber (SMF) |
| Maximum Distance | Up to 100 meters | Up to 300 meters (MMF), Up to 40 kilometers (SMF) |
| Connector Type | RJ-45 | LC duplex |
| Digital Optical Monitoring (DOM) | No | Yes |
| Compliance | IEEE 802.3, IEEE 802.3ab | SFP+ MSA, IEEE 802.3ae |
| Operating Temperature Range | 0°C to 70°C (32°F to 158°F) | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature Range | -40°C to 85°C (-40°F to 185°F) | -40°C to 85°C (-40°F to 185°F) |
| Hot-Swappable | Yes | Yes |
| EMI Compliance | FCC Part 15 Class B, EN 55022 Class B | FCC Part 15 Class B, EN 55022 Class B |
| Safety | Laser Class 1 (IEC 60825-1, 60825-2) | Laser Class 1 (IEC 60825-1, 60825-2) |
| Dimensions (H x W x D) | 8.5 mm x 13.4 mm x 56.5 mm | N/A |
| Weight | Approximately 75 grams (0.165 lbs) | N/A |
Cisco GLC-T SFP Transceiver Module
| Specification | Description |
|---|---|
| Model | Cisco GLC-T |
| Type | SFP (Small Form-Factor Pluggable) Transceiver Module |
| Data Rate | 1 Gbps (Gigabit Ethernet) |
| Connector Type | RJ-45 |
| Cable Type | Category 5e or higher unshielded twisted-pair (UTP) copper cabling |
| Maximum Distance | Up to 100 meters |
| Compliance | IEEE 802.3, IEEE 802.3ab |
| Hot-Swappable | Yes |
| Operating Temperature Range | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature Range | -40°C to 85°C (-40°F to 185°F) |
| Operating Humidity | 5% to 95% non-condensing |
| Power Consumption | Low power consumption |
| Input Voltage | 3.3V |
| EMI Compliance | FCC Part 15 Class B, EN 55022 Class B |
| Safety | Laser Class 1 (IEC 60825-1, 60825-2) |
| Dimensions (H x W x D) | 8.5 mm x 13.4 mm x 56.5 mm |
| Weight | Approximately 75 grams (0.165 lbs.) |
| Compatibility | Compatible with a wide range of Cisco switches, routers, and other networking devices |
