? Message us on In today’s connected business world, speed alone doesn’t cut it anymore. Companies now demand power, security, visibility, and smart design — all in one place. The USW-Enterprise-8-PoE Ubiquiti Enterprise 8 PoE Switch rises to meet these expectations. Designed by Ubiquiti, a brand trusted by IT professionals globally, this switch blends high-performance switching with PoE+ capability, intuitive management, and a sleek build that fits right into modern office or enterprise environments.
Full Overview of USW-Enterprise-8-PoE Ubiquiti Enterprise 8 PoE Switch
The USW-Enterprise-8-PoE is a next-generation Layer 2 and Layer 3 switch from Ubiquiti’s UniFi Enterprise series. Featuring 8 ultra-fast 2.5GbE RJ45 ports with PoE+ support and a single 10G SFP+ uplink, this Ubiquiti switch offers a rare combination of performance and flexibility in a compact desktop form factor.
Built to simplify power and data distribution, each of the 8 Ethernet ports delivers up to 30W of PoE+ power, with a total PoE budget of 120W. This means you can connect high-performance UniFi access points, VoIP phones, surveillance cameras, and other PoE devices without requiring additional power injectors or cabling mess.
In addition to hardware power, Ubiquiti has integrated a 1.3″ LCM color touchscreen on the front panel for real-time device monitoring, IP address display, and quick diagnostics. It’s powered and controlled through the UniFi Controller or UniFi Network Application, offering intuitive management, traffic monitoring, VLAN configuration, and Layer 3 routing—all from one clean interface.
Use Cases for USW-Enterprise-8-PoE in Real Deployments
Whether you’re designing an edge network for a small office or looking to expand a corporate LAN with PoE endpoints, the USW-Enterprise-8-PoE Ubiquiti Enterprise 8 PoE Switch fits naturally into several environments:
- Remote Offices: Perfect for branch offices that need a compact but capable switch with fiber uplink support.
- Surveillance Setups: Directly power IP cameras with PoE+, eliminating the need for external power adapters.
- Retail Environments: Combine access points, POS terminals, and IP phones in one efficient solution.
- Classrooms and Labs: Deliver clean and managed connectivity to smartboards, Wi-Fi devices, and VoIP handsets.
Port Breakdown and PoE Capacity
- 8 × 2.5GbE RJ45 Ports with PoE+ Support
- IEEE 802.3at/af compliant
- Up to 30W per port
- 1 × 10G SFP+ Port
- Ideal for high-speed uplinks
- Total Power Budget: 120W
- Efficient distribution for medium-power PoE devices
- Switching Capacity: 80 Gbps
- Forwarding Rate: 59.52 Mpps
This configuration allows seamless deployment of multiple devices while ensuring high bandwidth and consistent power delivery.
Build Quality, Design, and Reliability
This switch isn’t just about specs — it’s about long-term reliability. The USW-Enterprise-8-PoE comes in a clean, matte-gray anodized aluminum enclosure that offers both durability and modern aesthetics. It’s fanless, meaning it operates silently — a key feature for offices, classrooms, and workspaces where noise matters.
The LCM touchscreen not only looks professional but adds meaningful functionality by providing real-time feedback on port activity, system status, and device identity. Internally, industrial-grade components ensure thermal stability and long operating life, even in challenging environments.
Managing VLANs with Ease
Network segmentation has never been easier. Using the UniFi Controller, you can create and manage VLANs across all ports to separate traffic by department, device type, or priority. The USW-Enterprise-8-PoE Ubiquiti Enterprise 8 PoE Switch handles complex VLAN topologies smoothly and visually through the UniFi dashboard.
Silent Desktop or Wall-Mount Deployment
With its fanless design and compact body, this switch is ideal for environments where space and silence are key. Whether sitting on a desk, mounted under a counter, or placed in a small rack, the USW-Enterprise-8-PoE stays unobtrusive and cool—literally and figuratively.
Comparison with Similar Ubiquiti Switches
| Feature | USW-Enterprise-8-PoE | USW-Lite-8-PoE | USW-Pro-8-PoE |
|---|---|---|---|
| PoE Standard | PoE+ (802.3at/af) | PoE (802.3af only) | PoE+/PoE++ |
| Ports | 8 × 2.5GbE + 1 × SFP+ | 8 × 1GbE | 8 × 1GbE + 2 × SFP |
| Max PoE Budget | 120W | 52W | 123W |
| Touchscreen | Yes (1.3″ LCM) | No | No |
| Management | UniFi Controller | UniFi Controller | UniFi Controller |
| Use Case | Enterprise/High-speed | Home/Small Office | Small-Medium Business |
Technical Specifications Table
| Specification | Detail |
|---|---|
| Model | USW-Enterprise-8-PoE |
| Switching Capacity | 80 Gbps |
| Forwarding Rate | 59.52 Mpps |
| RJ45 Ports | 8 × 2.5GbE with PoE+ |
| SFP+ Ports | 1 × 10G SFP+ |
| PoE Standard | IEEE 802.3at/af |
| Total PoE Budget | 120W |
| Management | UniFi Controller (Web/Mobile) |
| LCD Screen | 1.3″ Touchscreen Display |
| Cooling | Fanless |
| Mounting | Desktop / Wall mount |
| Operating Temperature | -5°C to 40°C (23°F to 104°F) |
| Dimensions | 204 × 120 × 37 mm |
| Weight | 1.2 kg |
| Power Method | AC Input or DC Terminal Block |
Frequently Asked Questions (FAQ)
1. Can I power UniFi U6 access points with this switch?
Yes, the PoE+ ports provide up to 30W per port, suitable for U6 APs.
2. Does the switch support Layer 3 routing?
Yes, basic Layer 3 functions like static routing and inter-VLAN routing are supported.
3. Is this switch silent?
Absolutely. It’s fanless and operates quietly, ideal for office environments.
4. Can I mount it on a wall?
Yes, it supports both desktop and wall-mount deployment.
5. How do I manage the switch?
Use the UniFi Controller or UniFi Network App for full configuration and monitoring.
6. Does the SFP+ port support fiber uplinks?
Yes, it’s designed for high-speed 10G fiber uplinks.
7. Can I use it with non-UniFi devices?
Yes, it works with any standards-compliant network device.
8. What is the warranty period?
Typically 1 year, but check with your reseller. ITMan offers full warranty support.
9. Can I limit PoE power per port?
Yes, the UniFi Controller allows power budgeting and per-port control.
10. Is this switch stackable?
Not physically, but can be logically managed with other UniFi switches via controller.
Final Verdict
The USW-Enterprise-8-PoE Ubiquiti Enterprise 8 PoE Switch delivers enterprise-grade performance in a sleek, compact form. It’s ideal for businesses that demand high-speed connectivity, modern PoE+ support, quiet operation, and complete software-defined control. Whether you’re upgrading your office network or building out a surveillance deployment, this switch provides the power, flexibility, and intelligence to handle it.
Reviews
There are no reviews yet.
