When building a modern enterprise network, the backbone switch plays a critical role in ensuring speed, scalability, and reliability. The Ubiquiti USW-Pro-Aggregation is designed exactly for this purpose. As a high-performance, Layer 2/3 managed aggregation switch, it brings multiple 10G SFP+ uplinks together into a single, highly efficient network core. Whether you are connecting distribution switches, powering a server room, or building a high-capacity network for a business, the USW-Pro-Aggregation offers exceptional performance with UniFi’s powerful software ecosystem.
This switch is particularly popular among IT managers, system integrators, and enterprise network designers who want to consolidate multiple switches and uplinks into a central aggregation point. It not only boosts throughput but also simplifies management with UniFi Controller integration. For ITMan customers in Dubai and across the UAE, this product is a future-proof choice for high-density networks that require robust aggregation capabilities.
Detailed Product Overview : Ubiquiti USW-Pro-Aggregation Managed Switch
The Ubiquiti USW-Pro-Aggregation UniFi 8-Port 10G SFP+ Managed Aggregation Switch is engineered for businesses looking to create a powerful 10-gigabit network backbone. It features eight 10G SFP+ ports, providing lightning-fast connectivity for switches, servers, and storage devices. With full Layer 2 capabilities and limited Layer 3 features such as static routing, it enables seamless communication across different network segments.
Unlike unmanaged or basic switches, the USW-Pro-Aggregation is fully managed via the UniFi Network Controller, offering administrators centralized control, advanced monitoring, VLAN segmentation, and traffic analytics. The fanless design keeps the switch silent, making it suitable even for office environments where noise is a concern.
In addition, the switch is designed with enterprise reliability in mind. It supports link aggregation for bandwidth bonding, jumbo frames for large data transfers, and redundant power options with UniFi SmartPower RPS (USP-RPS). All these features make it ideal for networks that demand uninterrupted connectivity.
Why Choose the USW-Pro-Aggregation?
Choosing the right aggregation switch is crucial for high-performance networks. The USW-Pro-Aggregation provides a perfect balance between cost and enterprise-grade functionality. Its ability to handle 80 Gbps switching capacity makes it ideal for data-intensive applications such as video surveillance backhauls, virtualization clusters, and large Wi-Fi deployments with UniFi APs.
For businesses scaling their infrastructure, this switch offers future-proof investment—supporting 10G speeds that can accommodate increased bandwidth requirements for years to come.
Applications of the USW-Pro-Aggregation
The USW-Pro-Aggregation can be deployed in a variety of scenarios:
- Enterprise Core Switch – Perfect for acting as the central aggregation layer between multiple access switches.
- Data Center or Server Room – Connect servers, NAS devices, and hypervisors at 10Gbps for maximum performance.
- Campus or Multi-Building Network – Aggregate fiber links from different buildings into one high-speed backbone.
- High-Performance Surveillance Network – Support multiple NVRs and camera feeds without bottlenecks.
- Large UniFi Wi-Fi Installations – Ideal for aggregating traffic from dozens of UniFi switches and APs.
Port Configuration
One of the standout features of the USW-Pro-Aggregation is its 8x 10G SFP+ ports. This configuration gives you flexibility to connect multiple distribution or access switches, servers, or storage appliances at full 10-gigabit speeds. All ports are non-blocking and support auto-negotiation for optimal performance.
With the UniFi Controller, administrators can easily configure VLANs, apply link aggregation (LACP), monitor real-time throughput, and troubleshoot issues with UniFi’s built-in analytics. The switch also supports jumbo frames up to 9000 bytes, which is essential for storage and virtualization networks that rely on efficient large-packet transfers.
Simplifying Server Room Cabling
When multiple distribution switches feed into a server room, cabling can get complicated fast. Deploying the USW-Pro-Aggregation allows you to reduce clutter by consolidating those connections into a single switch. With eight SFP+ ports, you can run fiber from each distribution switch into one central aggregation point, making troubleshooting and capacity planning much easier.
Preparing for 10G Expansion
Even if your current network is running at 1G, installing the USW-Pro-Aggregation future-proofs your infrastructure. You can gradually upgrade switches or servers to 10G without replacing the core switch. This phased approach is perfect for businesses that want to scale performance while keeping costs manageable.
Comparison with Similar Ubiquiti Products
| Model | Ports | Switching Capacity | Layer 3 Support | Ideal Use Case |
|---|---|---|---|---|
| USW-Pro-Aggregation | 8x 10G SFP+ | 160 Gbps | Static Routing | Core aggregation, high-density backhaul |
| USW-Enterprise-8-PoE | 8x 2.5G + 2x 10G SFP+ | 160 Gbps | Advanced Layer 3 | High-performance access layer with PoE |
| USW-Pro-24 | 24x 1G + 2x 10G SFP+ | 44 Gbps | Limited Layer 3 | Distribution layer for office networks |
| USW-Aggregation | 8x 10G SFP+ | 160 Gbps | Layer 2 only | Budget-friendly aggregation switch |
This table highlights why the USW-Pro-Aggregation is the go-to choice if you want Layer 3 static routing and full 10G aggregation capabilities without overspending on larger chassis-based switches.
Technical Specifications
| Specification | Details |
|---|---|
| Model | Ubiquiti USW-Pro-Aggregation |
| Part Number | USW-Pro-Aggregation |
| Ports | 8x 10G SFP+ |
| Switching Capacity | 160 Gbps |
| Forwarding Rate | 119 Mpps |
| Layer Support | Layer 2 + Static Layer 3 Routing |
| Management | UniFi Network Controller |
| Power Supply | Internal AC/DC, Optional USP-RPS Redundant Power |
| Cooling | Fanless |
| Mounting | Rack-mountable (1U) |
| Dimensions | 442.4 x 285.4 x 43.7 mm |
| Weight | 3.17 kg |
| Operating Temperature | -5°C to 40°C |
FAQ – Frequently Asked Questions
- Does the USW-Pro-Aggregation support Layer 3 routing?
Yes, it supports basic static routing, which is useful for inter-VLAN routing. - Can I mix copper and fiber SFP+ modules?
Yes, you can use both fiber and RJ45 10G SFP+ modules as long as they are UniFi-compatible. - Is the switch silent?
Yes, it has a fanless design, making it completely silent. - Can I manage it without the UniFi Controller?
Basic functionality works, but full configuration and monitoring require the UniFi Controller or UniFi Cloud. - Does it support jumbo frames?
Yes, up to 9000 bytes. - What is the maximum power consumption?
Approximately 20W under typical loads. - Does it support link aggregation (LACP)?
Yes, you can bond ports to increase throughput. - Can it be powered redundantly?
Yes, with the optional USP-RPS power backup unit. - What kind of businesses should buy this switch?
Any business with multiple distribution switches, a server room, or high-bandwidth applications. - Where can I buy USW-Pro-Aggregation in Dubai?
You can purchase it directly from ITMan.ae with delivery across the UAE and GCC.
Conclusion
The Ubiquiti USW-Pro-Aggregation is a powerhouse when it comes to building a 10G aggregation layer for your network. With eight 10G SFP+ ports, silent operation, and UniFi Controller management, it is perfect for medium to large businesses looking to scale their infrastructure. Its Layer 2/3 capabilities make it versatile for both simple and complex network topologies.
For ITMan customers, this switch is an excellent long-term investment that ensures your network is ready for the growing demand of bandwidth-intensive applications, cloud services, and virtualization.
